Straight shank core drills
-
Aufnahmetyp, maschinenseitig: Zylinderschaft -
Ø-Toleranz: h8 -
Norm: DIN 344 -
Oberfläche: dampfbehandelt -
Schneidrichtung: rechts -
Typ: N -
Spitzenwinkel: 120 -
Schneidstoff: HSS -
Innenkühlung: ohne
relieved cone • especially high rigidity • for pre-drilled/pre-cast/pre-punched holes • with tang to DIN 1809 • corrects alignment inaccuracies • corrects circularity errors • improves surface quality of hole • chamfer dia. < tapping size hole • observe min. pilot hole diameter "d0" • perfect finish reaming after core drilling
SKU
533
ISO code
| P | Steel, high-alloyed steel |
|---|---|
| M | Stainless steel |
| K | Grey cast iron, spher, graphite/mall. cast iron |
| N | Aluminium and other non-ferrous metals |
| S | Special, super and titanium alloys |
| H | Hardened steel and chilled cast iron |
On the following programme pages you will find for every tool recommendations regarding suitability for the application groups and details of max. tensile strength and harness:
optimal suitability
limited suitability
optimal suitability
limited suitability
Available in many variants
